If a magic packet that is directed to the device's MAC address is received, the NIC signals the computer's power supply or motherboard to initiate system wake-up, in the same way that pressing the power button would do. Powered-down computers capable of Wake-on-LAN will contain network devices able to listen to incoming packets in low-power mode while the system is powered down. The magic packet contains the MAC address of the destination computer, an identifying number built into each network interface controller (NIC), that enables it to be uniquely recognized and addressed on a network. WoL is implemented using a specially designed frame called a magic packet, which is sent to all computers in a network, among them the computer to be awakened. Principle of operation Įthernet connections, including home and work networks, wireless data networks, and the Internet itself, are based on frames sent between computers. In April 1997, this alliance introduced the Wake-on-LAN technology. In October 1996, Intel and IBM formed the Advanced Manageability Alliance (AMA). The WoL and WoWLAN standards are often supplemented by vendors to provide protocol-transparent on-demand services, for example in the Apple Bonjour wake-on-demand ( Sleep Proxy) feature. It is also possible to initiate the message from another network by using subnet directed broadcasts or a WoL gateway service. The message is usually sent to the target computer by a program executed on a device connected to the same local area network. If the computer being awakened is communicating via Wi-Fi, a supplementary standard called Wake on Wireless LAN (WoWLAN) must be employed. Wake-on-LAN ( WoL or WOL) is an Ethernet or Token Ring computer networking standard that allows a computer to be turned on or awakened from sleep mode by a network message.Įquivalent terms include wake on WAN, remote wake-up, power on by LAN, power up by LAN, resume by LAN, resume on LAN and wake up on LAN. This question was originally at but then I was told to ask it here instead.Mechanism to wake up computers via a network A physical Wake-on-LAN connector (white object in foreground) featured on the IBM PCI Token-Ring Adapter 2 How can I achieve my goal of waking a computer that is attached to the router, given that no other devices are physically attached to the router (and instead are only connected via wifi)? Thanks! I figured that the only hardwire requirement was that the sleeping computer needed to have an ethernet cable between it and the router (which mine does).īut it finally occurred to me: maybe wake-on-LAN only would only work if my sending computer were also hardwired to the router.

WOL WAKE ON DIRECTED PACKET WAKE ON MAGIC PACKET WINDOWS 10

Windows 10 computer, or Ubuntu in WSL on Win 10, or Android).Ĭalling this seems to have no effect: wakeonlan 00:26:9e:89:c9:e5

WOL WAKE ON DIRECTED PACKET WAKE ON MAGIC PACKET HOW TO

I've spent hours trying to figure out how to send a Magic Packet from one of my other devices (e.g. It's the only device plugged in via ethernet cable. Plugged into that via ethernet is an Ubuntu computer that is often sleeping. I have an Arris BGW210-700 wifi router (which is required for AT&T fiber).
